13.6 Printing Procedure
────────────────────────────────────────────────────
13.6.5 Screen Hard Copy
NOTE
13.6.6 List Print
NOTE
13.6.7 Report Print
NOTE
The display contents of the all screens can be printed out as is.
Procedure
Screen: All
1. Display the desired screen.
2. Press the COPY key.
･ Even if the gauge is set to the List & Gauge function, the gauge is not
printed out in the screen copy mode. The screen hard copy function is not
available during measurement.
･ Output destination by the COPY key can be selected. See Section 13.4.4.
The settings for the various functions made with the STATUS screen,
CHANNEL screen etc. can be printed out in list format.
Procedure
Screen: Excluding Waveform display
Press the PRINT key on the screen excluding Waveform display.
The list to be printed contains the setup conditions for the acquired
waveforms. Even if the settings are changed following wave acquisition, the
contents of the list remain unchanged.
Prints the waveform (in the range displayed on the Waveform display
screen), upper and lower values, and analog channel settings on A4 size
paper.
・If the A and B cursors are displayed on the screen, they are also printed.
・When "
COMMENT
"or"
SET & COM
" is set, the comments are also printed
(see Section 9.9).
Procedure
Screen: Waveform display
1. Display the Waveform display screen.
2. Press the FEED key and COPY key simultaneously.
(Press and hold the FEED
key and then press the
COPY
key.)
In FFT function, this function is not available.
