4.3 ST ATUS Settings (MEM)
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
4.3.3 Setting the Recording Length
Function
display
Meaning
:
Move the cursor up in the selection window.
:
Move the cursor down in the selection window.
Function
display
Meaning
:
Increases in number.
:
Decreases in number.
NOTE
The relation between number of channels and maximum recording length
Memory capacity
(words)
Maximum recording length (DIV)
16 channels 8 channels 4 channels 2 channels
8M
32 M
5000
20000
10000
40000
20000
80000
40000
160000
The length of recording for one measurement operation (number of DIV) can
be set.
SELECT Select the recording length.
ARBITRARY Variable recording length can be selected by the user.
Screen: STATUS1, Waveform display
Procedure 1 Constant recording length mode
1. Use the Menu keys to display the desired screen.
2. Move the flashing cursor to the
shot
item and select
SELECT
.
3. Use the Jog/Shuttle control or the function keys to make a setting.
Procedure 2 Variable recording length mode
1. Use the Menu keys to display the desired screen.
2. Move the flashing cursor to the
shot
item and select
ARBITRARY
.
3. Use the Jog/Shuttle control or the function keys to make a setting. To
change the column, use the cursor keys ( ).
･ Depending on the number of channels, the recording length is limited.
(For setting the number of channels, see Section 12.2.1.)
･ If the recording length is changed during measurement, measurement is
restarted using the newly set recording length.
･ In fixed-length recording mode, the symbol "*" in the selection window
indicates the recording length of the data stored to current memory. (If no
data is present in memory, this symbol is not displayed.) In any recording-
length mode, the symbol "#" is displayed before the recording length.
