308
────────────────────────────────────────────────────
13.7 External Printer (color print)
────────────────────────────────────────────────────
Connecting the PRINTER CARD
Connect the printer card to the unit.
See Section 14.3.1.
Setting the external printer
Turn on the external printer.
Load A4-size sheets and prepare the printer for
printing.
Setting the interface
For details on settings, see Sections 13.4.4 and
13.4.5.
Output destination
Set the output destination by
PRINT
key and
COPY
key to external printer.
Output color
Select the color of the output.
Print driver
Set the control code ("ESC/P" or "ESC/P
Raster") according to the printer to be used
Print size
Set the print size to
×
0.8 or
×
1
Indent width
Adjust the indent width (margin) within the
range of 0 to 10 mm from the upper edge of the
screen.
Saving the data in memory
Save "newly measured data" or "data saved to
the media" in the internal memory of the unit.
For details on load, see Section 14.8.
Specifying the printout range
Press the
DISP
key; the Waveform display
screen will appear. Using cursors A and B, the
print range can be specified. For information on
how to use cursors A and B, see Section 11.2.
Printing starts
PRINT key
COPY key
When the
PRINT
key is pressed, the waveform
data is printed out at a rate of 25 divisions.
When the
COPY
key is pressed, the data shown
on the screen is printed out.
NOTE
13.7 External Printer (color print)
Using the 9559 PRINTER CARD, waveform data can be output on A4-size
sheets from the external printer in color or monochrome.
PRINT key: Prints out equivalent to 25 divisions waveform data or numerical
data.
COPY key: Prints out the screen hard copy.
With respect to the following items, the external printer differs from the
internal printer:
･ For the list and gauge functions, the list is printed out but the gauge is not
output. If the display format is the X-Y screen, however, the gauge is also
printed out.
･ The upper and lower limits are printed out for every page.
･ When both the upper-lower print function and 0 position comment function
are enabled, the upper-lower print function is performed first.
