18.5 Recorder Function
────────────────────────────────────────────────────
16
17
18
19
5
6
7
8
9
10
11
12
13
14
A
Time axis
20
*1
,50
*1
,100
*1
,200
*1
, 500 ms/DIV
1, 2, 5, 10, 30 s/DIV 1, 2, 5, 10, 30 min/DIV 1 h/DIV
Time axis resolution
100 points/DIV (with the printer)
Sampling period
1, 10, 100
μ
s, 1, 10, 100 ms
(Can be selected, from 1/100 of the time axis setting)
Recording length
Standard (8 M): 25,50,100,200,500,1000,2000 DIV,CONT
*2
Expansion (32 M): 25,50,100,200,500,1000,2000,5000,10000 DIV,CONT
*2
Arbitrarily (Set from 1 division to the maximum number of divisions at 1-
division intervals.)
X-Y format can be set CONT only
Screen/print format
The styles single, dual, quad, oct (LCD) / hex
（
Print only), X-Y single /
X-Y dual (dot/line) are available.
Interpolation
Line
（
excluding X-Y format
）
,Dot
･
line
（
X-Y format
）
Recording line display
12-color
（
LCD
）
, Printout: 4-type
X-Y Spatial resolution
32 dots/DIV (with the display)
80 dots/DIV (horizontally), 80 dots/DIV (vertically) (with the printer)
X-Y Sampling period
Dotdisplay:300
μ
s fixed, Line display: 300
μ
sto25ms(notfixed)
Waveform magnification/
compression
Time axis
×
1,
×
1/2,
×
1/5,
×
1/10,
×
1/20,
×
1/50,
×
1/100,
×
1/200,
×
1/500
Measurement range
×
10,
×
5,
×
2,
×
1,
×
1/2
（
single
）
×
5,
×
2.5,
×
1,
×
1/2,
×
1/4
（
2, 4, 8, 16, X-Y1/2
）
Waveform storage
Last 2000 divisions of data saved in memory *3
Can be checked by reverse scrolling and reprinted
Print function
ON/OFF and reprinted
A4 print
Available
Additional recording function
ON/OFF
*4
Logging function
Records measured data as digital values
Variable function
Provided
18.5 Recorder Function
（
*1
）
: Although real-time recording to the recording paper is not possible in the high-speed range (20 to 200
ms/DIV), the waveforms are stored to the memory and can therefore be monitored on the screen. The
last 2000 divisions of each waveform
(*3)
are retained in memory before the measurement is complete.
If the recording length is not set to "continuous," the printer can also be operated, enabling the
waveforms to be printed out later.
（
*2
）
: With time axis 20 to 200 ms/DIV, "continuous" is not possible with printer ON.
（
*3
）
: Expanded to 32 M words: 10000 DIV
（
*4
）
: Additional recording function (recording data without paper)
When enabled, the memory is regarded as printer paper. Recording starts at the end of previous data,
without erasing them. When the 2000 DIV
*3
has been reached, old data will be overwritten. When
OFF, previous data will be erased. Set to ON if erasing is not desired.
