Hioki 8841 - Chapter 16 Waveform Operation Function; Waveform Parameter Calculation (MEM)

353
────────────────────────────────────────────────────
16.1 Waveform Parameter Calculation (MEM)
────────────────────────────────────────────────────
16
17
18
19
5
6
7
8
9
10
11
12
13
14
A
Chapter 16
Waveform Operation Function
16.1 Waveform Parameter Calculation (MEM)
・Available for memory recorder function and REC&MEM function.
The Memory waveform for the Record & Memory function is performed
with the Memory recorder function.
・Parameters that were used for captured waveform data and for data after
waveform processing can be determined. The result is shown in numeric
form.
・The A･B cursors (vertical, trace) can be used to determine the parameters of
a certain range.
・The following 14 types of calculations are possible:
(1) Average value, (2) RMS value, (3) peak-to-peak value
(4) Maximum value, (5) time to maximum value, (6) minimum value,
(7) time to minimum value, (8) period, (9) frequency, (10) rise time,
(11) fall time, (12) standard deviation, (13) area value, (14) X-Y area value
