Hioki 8841 - Setting the Recording Length

103
────────────────────────────────────────────────────
7.3 STATUS Settings (REC&MEM)
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
20ms 50ms 100ms 200ms 500ms 1s 2s 5s 10s 30s 1min 2min 5min 10min 30min 1hour
100
μ
s
●●●●●●●●●●●●● ●●●
200
μ
s
●●●●●●●●●●●●● ●●●
500
μ
s
●●●●●●●●●●●●● ●●●
1ms
●●●●●●●●●●●●● ●●●
2ms
●●●●●●●●●●●●● ●●●
5ms
●●●●●●●●●●●●● ●●●
10ms
− ● ● ● ● ● ● ● ● ● ● ● ● ●●●
20ms
− − ● ● ● ● ● ● ● ● ● ● ● ●●●
50ms
− − − ● ● ● ● ● ● ● ● ● ● ●●●
100ms
− − − − ● ● ● ● ● ● ● ● ● ●●●
200ms
− − − − − ● ● ● ● ● ● ● ● ●●●
500ms
− − − − − − ● ● ● ● ● ● ● ●●●
1s
− − − − − − − ● ● ● ● ● ● ●●●
2s
− − − − − − − −●●● ● ● ●●●
5s
− − − − − − − − −●● ● ● ●●●
10s
− − − − − − − − − − ● ● ● ●●●
30s
− − − − − − − − − − −●● ●●●
1min
− − − − − − − − − − − − ● ●●●
2min
− − − − − − − − − − − − − ●●●
5min
− − − − − − − − − − − − − −●●
7.3.3 Setting the Recording Length
Function
display
Meaning
:
Move the cursor up in the selection window.
:
Move the cursor down in the selection window.
Combination of the recorder and memory time axis range.
Vertical axis: time axis range of memory waveform (/DIV), horizontal axis:
time axis range of recorder waveform (/DIV)
The length of recording for one measurement operation (number of DIV) can
be set.
The recording lengths for the recorder and memory are set separately. Two
setting methods are available.
SELECT
Select the recording length.
ARBITRARY
Variable recording length can be selected by the user.
Screen: STATUS1, Waveform display
Procedure 1 Constant recording length mode
1. Use the Menu keys to display the desired screen.
2. Move the flashing cursor to the shot item.
3. To set the recording length, move the flashing cursor to either Recorder or
Memory, according to which is to be set, and select SELECT.
4. Use the Jog/Shuttle control or the function keys to make a setting.
