5.6 Start and Stop Operation (REC)
────────────────────────────────────────────────────
Setting the 8841/42
STATUS Settings
Channel Settings
Trigger Settings
Trigger condition
are met
Measurement start
Recording start
Recording end
Measurement end
Trigger mode: SINGLE
REPEAT
5.6 Start and Stop Operation (REC)
See Section 5.3, "STATUS Settings", Chapter 9, "Input Channel
Settings", Chapter 10, "Trigger Functions."
Press the START key and LED light.
When the trigger can be registered, the indication "Waiting for
trigger" is shown on the display.
Data recording starts when trigger condition are met.
(trigger timing: start, start&stop)
Displays "Storing".
When the time axis is 20 to 50 ms/DIV, the waveforms are
compressed and displayed.
If the printer is on, printing initiates simultaneously with
display. When the time axis is 20 to 200 ms/division, printing
is performed as follows.
Using the VIEW key to display the time (from measurement
started time).
When automatic storage is enabled and measurement is
interrupted in progress, measurement data taken prior to the
interruption point is stored automatically.
Auto saving is executed.
End of measurement
Each time when trigger conditions are met, data are recorded
and memory contents are overwritten.
(Trigger timing: start / start&stop)
Data recording starts.
(Trigger timing: stop)
End of measurement in REPEAT trigger modes
When STOP key is pressed, measurement stops
