Chapter 5
Recorder Function
5.1 Overview of the Recorder Function
The recorder function has the following features.
(1) Real time display and printing of the input signal
(2) Real time continuous recording of the input signal
(3) All input channel data are recorded on the same time axis.
Since data for all channels can be superimposed, the relative relationship
between input signals can be observed visually.
(4) Time axis setting
20 ms/DIV to 1 h/DIV
(5) Time axis resolution 100 points/DIV (printer)
(6) Sampling period
1, 10, 100μs, 1, 10, 100 ms（Can be selected, from 1/100 of the time axis
setting）
(7) Memory capacity
・8 M words: 2000 DIV
・32 M words: 10000 DIV
・Arbitrarily (Set from 1 division to the maximum number of divisions at 1-
division intervals)
(8) Waveform magnification/compression display and printout
・Time axis direction: ×1to×1/500
・Voltage axis direction: ×10 to ×1/2 (single)
×5to×1/4 (dual to hex, X-Y single/dual) 5 steps
・With the variable function, vernier function
(9) Display format
・Time axis waveform: single, dual, quad, oct screen display (LCD), hex
screen display（printer only）
・X-Y waveform: single, dual
