197
────────────────────────────────────────────────────
9.11 Setting the 8937 VOLTAGE/TEMP UNIT
────────────────────────────────────────────────────
Flashing cursor
Function
display
Meaning
g-rj1, rj2
:
Reference junction compensation is performed internally
by the 8937.(Measurement accuracy is the sum of the
accuracy of temperature measurement plus reference
junction compensation accuracy.)
:
Reference junction compensation is not performed by
the 8937. Select this option when using an external
reference junction compensation unit. (Measurement
accuracy refers only to the accuracy of temperature
measurement.
)
:
Internal: No underline appears below C.
:
External: The underline appears below C.
Measurement range 10
o
C/DIV 20
o
C/DIV 50
o
C/DIV 100
o
C/DIV
Upper limit of
measurement input
400
o
C 800
o
C 2000
o
C 4000
o
C
Lower limit of
measurement input
-92
o
C -184
o
C -460
o
C -920
o
C
Measurement input
range:
-200
o
C to 200
o
C
Measurement range:
20
o
C/DIV
0
o
C
500
o
C
-500
o
C
Thermocouple: T
Measurement input
range
400
o
C
-200
o
C
When upper limit of
measurement input
range is exceeded
When lower limit of
measurement input
range is exceeded
-460
o
C
0
o
C
200
o
C
-200
o
C
When measurement
input lower limit is
exceeded
-184
o
C
When thermocouple measurement
range is exceeded
When lower limit of measurement input
is exceeded
Measurement input
range:
-200
o
C to 400
o
C
Measurement range:
50
o
C/DIV
(3) Set the reference junction compensation.
1. Move the flashing cursor to the point shown in the
figure on the left.
2. Use the function keys to make a setting.
Discriminating between internal and external reference junction
compensation
Measurement range and upper and lower limits of measurement input
Note that the upper and lower limits of measurement input vary according to
measurement range. Waveform saturation will result if the limits indicated in
the table below are exceeded.
Examples of waveform display measurement according to measurement
range (Position: 50%, magnification/compression ratio: ×1, NORMAL
screen, thermocouple: T)
