94
────────────────────────────────────────────────────
6.3 ST ATUS Settings (RMS)
────────────────────────────────────────────────────
Function
display
Meaning
:
Data are stored as binary data.
:
Dataarestoredastextdata.
Function
display Meaning
:
Move the cursor up in the selection window.
:
Move the cursor down in the selection window.
NOTE
5. Move the flashing cursor to type, and select the format.
Data stored in the text format is not readable by the 8841/42.
6. When the data format to be saved is set to text data, the intermittent setting
item is displayed. Use the function keys or Jog/Shuttle control to make a
setting.
7. Set the file name. For the input method, refer to Section 9.9.3.
When using auto-save, a number is appended to the name you specify as the
file name. This then becomes the file name. If you start procedures before
specifying a file name, AUTO is automatically enabled.
When the characters below are used in a file, the file cannot be handled on a
PC running Windows 2000 or XP. Do not use these characters when
handling a file on your PC.
Full-size lowercase letters a to z; full-size π, µ, ε; and half-size +, =, [, ]
･
File names consist of 8 characters (or 4 double-byte characters). With auto-
save, since numbers are attached to the end of file names, long file names
are truncated when this number is appended to the end of the file name.
･
With auto-save enabled, channel selection is disabled. Data for all channels
is saved.
･
For details on file name when auto-saving, see Section 14.7.
･
When the recording length is "CONT", data are not stored automatically.
･
For details on connected SCSI device, refer to Section 14.4.
･
When cursor A and B are enabled, partial saving is executed.
･
If additional recording is enabled, only newly acquired waveforms are saved.
Even when A and B cursors appear on the screen, no partial save is
performed.
･
During automatic storage, if the measurement is interrupted, waveforms
taken prior to the interruption are stored automatically.
･
The directory and the number of files that can be stored in the directory are
limited. For details, see Section 14.7.
･
When "COMMUNI" (communications) is selected as Media, Storage Method
and Type are not displayed.
