Hioki 8841 - Page 137

113
────────────────────────────────────────────────────
7.3 STATUS Settings (REC&MEM)
────────────────────────────────────────────────────
MEM time axis MEM recording
length
REC time axis REC recording
length
Maximum Recording
Time
50 ms 4000 200 ms 1000 3m, 20s
100 ms 5000 500 ms 1000 8m, 20s
200 ms 5000 1s 1000 16m, 40s
500 ms 4000 2s 1000 33m, 20s
1s 5000 5s 1000 1h, 23m, 20s
2s 5000 10 s 1000 2h, 46m, 40s
5s 6000 30 s 1000 8h, 20m, 00s
10 s 6000 1 min 1000 16h, 40m, 00s
30 s 4000 2 min 1000 1d, 09h, 20m, 00s
1 min 5000 5 min 1000 3d, 11h, 20m, 00s
2 min 5000 10 min 1000 6d, 22h, 40m, 00s
5 min 6000 30 min 1000 20d, 20h, 00m, 00s
MEM time axis MEM recording
length
REC time axis REC recording
length
Maximum Recording
Time
50 ms 20000 200 ms 5000 16 m, 40 s
100 ms 25000 500 ms 5000 41 m, 40s
200 ms 25000 1s 5000 1h,23m,20s
500 ms 20000 2s 5000 2h,46m,40s
1s 25000 5s 5000 6h,56m,40s
2s 25000 10 s 5000 13 h, 53 m, 20 s
5s 30000 30 s 5000 1d,17h,40m,00s
10 s 30000 1 min 5000 3d,11h,20m,00s
30 s 20000 2 min 5000 6d,22h,40m,00s
1 min 25000 5 min 5000 17 d, 08 h, 40 m, 00 s
2 min 25000 10 min 5000 34 d, 17 h, 20 m, 00 s
5 min 30000 30 min 5000 104 d, 04 h, 00 m, 00 s
■
Maximum Recording Time
The maximum settable recording time is determined by the space available
on the media, the MEM and REC time axes and the selected recording
length. However, the maximum REC recording length is limited to 1000 DIV
(5000 with expanded memory), so the recording time cannot be set beyond
this limit regardless of space available on the media.
The settable recording times for saving the 16 analog channels to PC card (1
GB) are shown below.
(1) With the REC time axis set to the fastest values with respect to the MEM
time axis (compression rate: small)
(2) With memory expanded, and the REC time axis set to the fastest values
with respect to the MEM time axis (compression rate: small)
