8.2 Operation Sequence (FFT)
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
Settings on the channel screen
Setting the input channel
Setting the trigger function
Start measurement
Stop measurement
Setting the system
･
Press the
START
key and the LED lights.
･
When the trigger conditions are met, measurement start.
･
Press the
STOP
key and the LED goes out after measurement has finished.
Waveform display color
Voltage axis range
Input coupling
Magnification/compression along voltage
Anti-aliasing filter
Zero position
Zero adjustment
Low-pass filter
Settings the advanced function
Comment function (See Chapter 9.9)
Trigger mode
Trigger source
Pre-trigger
Trigger selection
Processing measurement data
Printing the measurement data (See Chapter 13)
Saving the measurement data (See Chapter 14)
Measurements on display screen
Using the A
･
B cursor (See Section 11.2)
Set up (See Section 12.2)
Scaling (See Section 12.3)
Comment (See Section 12.4)
Interface (See Section 12.5)
Initialize (See Section 12.6)
Self-check (See Section 12.7)
Press the
SYSTEM
key to display the
SYSTEM screen. (See Chapter 12)
(See Chapter 9)
(See Chapter 10)
