8.3 STATUS1 Settings (FFT)
────────────────────────────────────────────────────
XandYAxisSettingsAvailablewitheachFFTAnalysisMode
FFT analysis mode
X-axis
(horizontal axis)
Y-axis
(vertical axis)
STR
Storage Waveform (Time) (Linear)
LIN
Linear Spectrum
LIN-Hz
LOG-Hz
LIN-REAL
LIN-IMAG
LIN-MAG
LOG-MAG
PHASE
RMS
RMS Spectrum
LIN-Hz
LOG-Hz
LIN-REAL
LIN-IMAG
LIN-MAG
LOG-MAG
PHASE
PSP
Power Spectrum
LIN-Hz
LOG-Hz
LIN-MAG
LOG-MAG
ACR
Auto Correlation Function (Time) (Linear)
HIS
Histogram (Volt) (Linear)
TRF
Transfer Function
LIN-Hz
LOG-Hz
LIN-REAL
LIN-IMAG
LIN-MAG
LOG-MAG
PHASE
CSP
Cross Power Spectrum
LIN-Hz
LOG-Hz
LIN-REAL
LIN-IMAG
LIN-MAG
LOG-MAG
PHASE
CCR
Cross Correlation Function (Time) (Linear)
IMP
Unit Impulse Response (Time) (Linear)
COH
Coherence Function
LIN-Hz
LOG-Hz
(Linear)
OCT
Octave Analysis
1/3 OCT
1/1 OCT
LIN-MAG
LOG-MAG
The item shown by brackets ( ), it is fixed.
