9.8 Scaling Function (SYST EM2)
────────────────────────────────────────────────────
Setting the scaling function
Setting the variable function
Convert the measurement to a physical quantity.
Set the unit (eu).
Set the upper and lower limits of variable setting usin
the converted (scaled) physical quantity.
Set the unit (eu) on the scaling setup screen.
1
2
The gauge unit indication [ ] is widened
(when the gauge is set to ON.)
[
V
]
50
45
40
35
[
VVVVVVVV
]
50
4
5
4
0
35
ＣＨ１■
100mV fs ( 5mV
×
1)
ＣＨ１■ -50 〜 50 [mV ]
Before scalin
g
A
fter scalin
g
Before scalin
g
A
fter scalin
g
The input channel is represented in full-span mode instead of full-scale mode,
and the unit is displayed in [ ]
■
Combination of the scaling and variable functions
The scaling function can be combined with the variable function. When
using the scaling and variable functions together:
With variable auto-calibration off (refer to Section 12.2.16):
Set the scaling first. If set in the sequence "Variable"
→
"Scaling," the upper
and lower limits must be set with physical values after conversion in the
variable settings (after scaling).
With variable auto-compensation on (refer to Section 12.2.16):
Even if the scaling settings are altered later, the waveform appearance will
not change significantly, since the variable settings are calibrated
automatically.
■
How to identify scaled data output
