13.1 Printout of Measurement Data Operating Procedure
────────────────────────────────────────────────────
1
2
3
19
5
6
7
8
9
10
11
12
13
14
A
SETUP
SCALING
COMMENT
INTERFACE
Printing
Press the
SYSTEM
key to make the
settings on the SYSTEM screen.
Grid type
Channel marker
Time value
List & Gauge
Printer density
Upper-lower print
0 position comment
Counter print
The printout will use the scaled gauge.
See Section 9.8.
Two types of comments - title comments
and channel-by-channel comments - may be
superimposed on a graph.See Section 9.9.
Output destination by COPY
Output destination by PRINT
Output destination is set by PRINT or COPY
To print with the unit, set to "INTERNAL
PRINTER".
Settings on the SYSTEM screen
Manual print
This mode serves to print waveform data
from the internal memory.
Auto print
Printout is carried out automatically after
a waveform has been captured for the
specified recording length. (MEM,FFT)
Real-time print
The input waveform and data are printed
out continuously in real time. (REC and
RMS, recorder waveform in REC&MEM)
Partial print
This function prints the waveform
between the A and B cursors (vertical or
trace cursors).
Screen hard copy
The display contents of the all screens
can be printed out as is.
List print
The settings for the various functions
made with the STATUS screen,
CHANNEL screen etc. can be printed
out in list format.
Report print
This function prints the waveform range
shown on the display, upper-lower value,
analog channel along with the active
settings.
External printer
Using the 9559 PRINTER CARD,
waveform data can be output on A4-size
sheets from the external printer in color
or monochrome.
