11
────────────────────────────────────────────────────
2.2 Power Supply and Ground Connections
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
Estimated battery operation hours (at room temperature)
Battery type: 12 V, 38 Ah, fully charged
Units
Operation
condition
8841 8842
8936 installed 8946 installed 8936 installed
Printer not used
(trigger waiting)
Approx. 9 h Approx. 7 h 30 min Approx. 7 h
Printer used
(recorder function
500 ms/DIV,
all store)
Approx. 2 h 50 min Approx. 2 h 40 min Approx. 2 h 40 min
Specification of the 9433 DC POWER ADAPTER
Accuracy at 23
±
5
, 35% to 80%RH, after 30-minutes warming-up time.
Input voltage range
10 to 28 VDC
Rated output voltage
24 VDC
Output voltage accuracy
24 VDC
±
2%
Rated output current
7A
Efficiency
70% or more
（
12 VDC input, rated output
）
Maximum rated power
250 VA
Temperature and humidity
range for use
0 to 40 (32 to 104 ), 35% to 85%RH
(with no condensation)
Temperature and humidity
range for storing
-20 to 60 (-4 to 140 ) 10% to 90%RH
(with no condensation)
Location for use
According to specifications for the 8841/8842
MEMORY HiCORDER
Dielectric strength
500 VDC for a minute
(between input and output, between input and unit)
Insulation voltage
100 M
Ω
or more / 500 VDC
(between input and output, between input and unit)
Dimensions
Approx. 110W
×
65H
×
150D mm (4.33"W
×
2.56"H
×
5.91"D)
Input cable: 2000 mm (78.7")
Output cable: 500 mm (19.69")
Mass
Approx. 1250 g (44.1 oz) approx.
Accessory
Spare fuse
（
class A melting fuse (NM)
30 A/125 V, 6.4 dia.
×
31.8 mm
）
Actual running time may differ, depending on battery age, charge condition,
ambient temperature, and other factors.
If the 9433 is connected to the 8841/8842, and the adapter switch is turned
on, even when the 8841/8842 runs off the AC power supply, the 9433
remains in standby mode and consumes some power.
In this case, the battery operation time is 95 hours.
