329
────────────────────────────────────────────────────
14.7 Saving the Data (SAVE)
────────────────────────────────────────────────────
"COMMENT","8841 MEM DATA"  
：
Comment character string
"DATE","01‑01‑1999"  
：
Date
（
month
−
day
−
year
）
"TIME","10:10:00"  
：
Time
"NUMSIGS", 3  
：
Number of signals
"INTERVAL", 1.000E‑06  
：
Horizontal axis interval
"HORZUNITS", "S"  
：
Horizontal axis unit
"VERTUNITS", "S", "V", "V"  
：
Vertical axis unit
"SIGNAL","TIME", "ACH 1", "ACH 2" 
：
Signal name
"DATA"  
：
Data start
+0.000000E+00, ‑5.9375E‑03, +9.3750E‑04
+1.000000E‑06, ‑5.6875E‑03, +7.5000E‑04
*1
*2
*1: Any set title comments are shown.
*2: Any set comment on each channel is shown.
"COMMENT","8841 MEM DATA"
"DATE","01-01-1999"
"TIME","10:10:00"
"NUM_SIGS", 9
"INTERVAL", 1.000E-06
"HORZ_UNITS", "S"
"VERT_UNITS", "S", "V", "V", "V", "V", "Bit", "Bit", "Bit", "Bit"
"SIGNAL","TIME", "ACH 1", "ACH 2", "ACH 3", "ACH 4", "LCHA1", "LCHA2",
"LCHA3", "LCHA4""DATA"
+0.000000E+00, -5.9375E-03, +9.3750E-04, +2.3500E-03, -9.3750E-04, 1,1,1,1
+1.000000E-06, -5.6875E-03, +7.5000E-04, +2.4125E-03, -1.0312E-03, 1,1,1,1
+2.000000E-06, -5.5000E-03, +6.2500E-04, +2.3688E-03, -1.0437E-03, 1,1,1,1
+3.000000E-06, -5.5000E-03, +6.2500E-04, +2.4000E-03, -1.1750E-03, 1,1,1,1
+4.000000E-06, -5.3750E-03, +4.3750E-04, +2.4000E-03, -1.1687E-03, 1,1,1,1
+5.000000E-06, -5.6250E-03, -5.1875E-03, +1.0250E-03, -1.2187E-03, 1,1,1,1
+6.000000E-06, +4.3750E-04, -7.6875E-03, -1.1250E-03, -9.3750E-05, 1,1,1,1
+7.000000E-06, +2.1875E-03, -6.1875E-03, -1.6875E-03, +8.0000E-04, 1,1,1,1
+8.000000E-06, +1.5625E-03, -6.5000E-03, -2.0687E-03, +1.1687E-03, 1,1,1,1
+9.000000E-06, +1.3750E-03, -6.3750E-03, -2.2500E-03, +1.3125E-03, 1,1,1,1
+1.000000E-05, +1.3750E-03, -6.2500E-03, -2.2875E-03, +1.4250E-03, 1,1,1,1
Text data store example
The text data are stored as follows. Depending on the function, the saving
method varies.
Example 1 When the data for analog 4 channels and logic 4 channels is stored in
Memory recorder function (Memory recorder function, memory data in
Recorder&memory function, FFT function)
