360
────────────────────────────────────────────────────
16.1 Waveform Parameter Calculation (MEM)
────────────────────────────────────────────────────
Setting the parameter
calculation
Executing the parameter
calculation
Setting the calculation
range
Displaying calculation
result
Internal memory data
Selecting the calculation
Loading from the media
Parameter evaluation
Processing the
calculation result
Parameter calculation
end
NOTE
Calculation of data stored in memory
Press the FILE key to display the FILE screen.
Read the measurement data. See Section 14.8
The measurement data stored in memory of the unit is
calculated.
The calculation range can be specified by the A and B cursors.
If the range is not specified, all measurement data is calculated.
For the A and B cursors, see Section 11.2, "Using the A･B
Cursors."
Press the STATUS key to display the parameter calculation
screen. Set the items. For details, see Section 16.1.1, "Making
Settings for Waveform Parameter Calculation."
Move the flashing cursor to
measurement
and select
(exec)
function key."measurement" is displayed.
The calculation result is displayed on the Waveform display
screen.
Depending on the results of the waveform parameter calculation,
a GO (pass) or NG (fail) result is returned.
When the evaluation result is GO:
･ Outputs GO signal.
When the evaluation result is NG:
･ Outputs NG signal.
･ The calculation value for that channel is marked with an "
*
"
(on the display and the printout).
Result to printer : ON →Prints the evaluation results.
Result save : ON →Saves the evaluation results.
･ Line cursor (horizontal) can not be set calculating ranges.
･ When only the cursor A is used, the waveform data from the position of
cursor A to the end of the data is calculated.
･ The result can be recalculated by altering the calculation process.
