16.2 Calcu lating Waveform Data
────────────────────────────────────────────────────
s1425-2
Function
display
Meaning
:
Increase value.
:
Decrease value.
:
End
Setting the number of moved point
1. Move the cursor to the position of the number of
moved point setting (MOV or SLI).
2. Move the cursor to each digits and make the setting
with the function keys or the Jog/Shuttle control.
To move the digit, use the cursor keys ( ).
For MOV (moving average): 1 to 4000
For SLI (parallel displacement): -4000 to +4000
To Next Page
