16.2 Calcu lating Waveform Data
────────────────────────────────────────────────────
Select the calculating
data
Measurement end
Setting the calculating
range
Setting the items
Internal memory data
Waveform calculation
Loading from media
Displaying
calculation result
Operating the result
NOTE
Waveform processing of data in internal memory or media
Press the
FILE key to display the FILE screen.
For details on LOAD, refer to Section 14.8.
Waveform calculation execute the stored measurement data.
This setting calculates the measurement data between A and B
cursors. When there is no A and B cursors, calculates all data.
(See Section 11.2)
Press the STATUS key to display the STATUS4 screen.
For details on setting, refer to 16.2.
Move the flashing cursor to
wave calculation
. And use the
function key to select
(exec)
.
Displays "Calculating".
Displays waveform calculation result on the screen.
Printout can be carried out.
Saving can be carried out.
･ The maximum recording length allowing waveform processing calculation is
1000 divisions (5000 divisions for 32 M words).
･ When using the trace cursor, the trace point value is displayed as processed
value.
･ When the cursors overlap, processing is carried out for that point.
･ Line cursor (horizontal) can not be set calculating ranges.
･ When only the cursor A is used, the waveform data from the position of
cursor A to the end of the data is calculated.
･ The result can be recalculated by altering the calculation process.
･ A stored waveform read by the Recorder & Memory function can be
subjected to waveform processing by the Memory function, but doing so
erases the Recorder waveform.
