18.2 External Data Sto rage and Interface
────────────────────────────────────────────────────
GP-IB
Complies with IEEE 488.2-1987
･
Remote control including input unit is possible.
･
The optional 9558 GP-IB CARD is used.
RS-232C
Complies with EIA RS-232C
･
Remote control including input unit is possible.
･
The optional 9557 RS-232C CARD is used.
Printer
Complies with PC-AT centronics
･
Using the external printer, color print can be printed.
･
The optional 9559 PRINTER CARD is used.
LAN
Complies with IEEE 802.3i
（
Ethernet 10BASE-T
）
･
Remote control including input unit is possible.
･
The optional 9578 10BASE-T LAN CARD is used.
･
Commercially available LAN cards (specified) can be used.
･
Remote control and data acquisition using the 9333 LAN
COMMUNICATOR are possible.
SCSI
ANSI X3.131-1986
（
SCSI level 2
）
JIS X6051
（
SCSI level 2
）
Driver/receiver
Single - ended
Bus-parity
Output data : none
Input data : none
Data transfer method
Asynchronous
Terminator
Provided (not removable)
Terminator power
Provided
Initiator operation
Provided
Target
3.5-inch MO disk
Address
0to7
Connector
･
Connect to MO disk drive with SCSI cable
･
Connector type: High density
（
pin-type
）（
D-Sub half-pitch 50 P
）
MO disk drive
Connect to MO disk drive with SCSI cable
Data stored
Settings, waveform evaluation area, screen data,
measurement data (binary or text),
(Measurement data can be saved between cursors A and B.)
spacing data (text)
Interface
SCSI Interface
