Hioki 8841 - Page 436

412
────────────────────────────────────────────────────
19.2 Analog Inputs
────────────────────────────────────────────────────
Compatible converter:
Charge-output type piezoelectric accelerator pickup sensor
Measurement sensitivity
0.1 to 10 pC/(m/s
2
)
Measurement range
2,5,10,20,50,100,200,500,1k,2k,5k,10 km/s
2
/DIV
（Measurement sensitivity: 0.1 to 0.25 pC/(m/s
2
)）
1,2,5,10,20,50,100,200,500,1k,2k,5 km/s
2
/DIV
（Measurement sensitivity: 0.251 to 0.5 pC/(m/s
2
)）
500m,1,2,5,10,20,50,100,200,500,1k,2 km/s
2
/DIV
（Measurement sensitivity: 0.501 to 1.0 pC/(m/s
2
)）
200m,500m,1,2,5,10,20,50,100,200,500,1 km/s
2
/DIV
（Measurement sensitivity: 1.01 to 2.5 pC/(m/s
2
)）
100m,200m,500m,1,2,5,10,20,50,100,200,500 m/s
2
/DIV
（Measurement sensitivity: 2.51 to 5.0 pC/(m/s
2
)）
50m,100m,200m,500m,1,2,5,10,20,50,100,200 m/s
2
/DIV
（Measurement sensitivity: 5.01 to 10.0 pC/(m/s
2
)）
Amplitude accuracy ±2%f.s
Temperature characteristic ±0.2%f.s./
o
C
Frequency characteristic
1 to 50 kHz(+1/-3 dB)
Low-pass filter
500, 5 kHz±50%(-3 dB)
Maximum input charge ±500 pC (with six high-sensitivity ranges selected)
±50,000 pC (with six low-sensitivity ranges selected)
Input terminal
Miniature connector（#10-32UNF）
Compatible converter:
Internal preamp type accelerator pickup sensor
Measurement sensitivity
0.1 to 10 mV(m/s
2
)
Measurement range
2,5,10,20,50,100,200,500,1k,2k,5k,10 km/s
2
/DIV
（Measurement sensitivity: 0.1 to 0.25 mV/(m/s
2
)）
1,2,5,10,20,50,100,200,500,1k,2k,5 km/s
2
/DIV
（Measurement sensitivity: 0.251 to 0.5 mV/(m/s
2
)）
500m,1,2,5,10,20,50,100,200,500,1k,2 km/s
2
/DIV
（Measurement sensitivity: 0.501 to 1.0 mV/(m/s
2
)）
200m,500m,1,2,5,10,20,50,100,200,500,1 km/s
2
/DIV
（Measurement sensitivity: 1.01 to 2.5 mV/(m/s
2
)）
100m,200m,500m,1,2,5,10,20,50,100,200,500 m/s
2
/DIV
（Measurement sensitivity: 2.51 to 5.0 mV/(m/s
2
)）
50m,100m,200m,500m,1,2,5,10,20,50,100,200 m/s
2
/DIV
（Measurement sensitivity: 5.01 to 10 mV/(m/s
2
)）
Amplitude accuracy ±2%f.s
Temperature characteristic ±0.2%f.s./
o
C
Frequency characteristic
1 to 50 kHz(+1/-3 dB) (low-end cutoff frequency = 1 Hz±50%)
Low-pass filter
500, 5 kHz±50%(-3 dB)
Drive power
2mA±20%, +15 V±5%
Input terminal
BNC connector
■ Charge Input
■ Input for Sensor Preamp
