• Feeder values changed during production are reflected in the preset.
• Feeder values changed during drain or full open lock are not reflected in the preset.
• For the [Feeder Adjustment] index screen during preset, refer to “6.11.4 [Feeder Adjustment]
Index Screen”.
• The following procedure is explained taking the [Feeder Adjust] tab screen of the
[Production] screen as an example.
7 [Section mean] key ON: Displays the graph of the average infeed product amount for each section.
The graph is graduated from the center to the periphery to indicate from 0% to
200% of WH capacity, setting the optimum quantity at 100%.
The values are displayed in red on the graph while the [Average Infeed
Product Amount] key for each section is selected.
If the key is not selected, the values are displayed in grey.
The values are indicated by a circle.
8 [Increase] key Increases the feeder value (RF time or RF amplitude) of the selected head.
9 [Decrease] key Decreases the feeder value (RF time or RF amplitude) of the selected head.
10 [Feeder] pop-up key Changes display of the [Feeder Adjustment] screen.
Displays the AFD setting menu in pop-up.
( 6.13.1 Switching Display in [Feeder Adjust] Screen)
11 Optimum feeder value range Displays the optimum feeder value range in pale green while the bar graph and
circle graph is displayed.
Make adjustment so that the head average and section average is within this
range.
12 [Radar chart display switching arrow]
key
Switches on/off the radar chart display also on the bird’s-eye view.
13 Bird’s-eye view Displays the selection status of the head or dispersion table to be adjusted.
14 Radar chart Displays the selection status of the head or dispersion table to be adjusted.
Displays the feeder time and amplitude of each head or dispersion table.
Table 6-45 Items and Functions of [Feeder Adjustment] Screen (Continued)
No. Name Function
To Next Page
