4535 611 98931 iE33 Service Manual Page 67
CSIP Level 1 Safety: Symbols
The following symbols are also used on the system:
Indicates that this device is protected against the effects of
immersion. This degree of protection can apply to transducers.
This product consists of devices that may contain lead or mercury,
which must be recycled or disposed of in accordance with local,
state, or federal laws.
Do not throw away. Dispose of in accordance with local, state, or
federal laws.
Connection for a pencil probe.
Connection for a transducer.
Connection for ECG.
Print remote output.
Input port for audio left/right, VHS/S-VHS, microphone, or DVD.
Output port for audio left/right, VHS/S-VHS, video patient monitor,
black-and-white printer or interlaced RGB output port.
IPX7
