4535 611 98931 iE33 Service Manual Page 68
CSIP Level 1 Safety: Symbols
The following symbols are used inside the system:
VGA or parallel output port.
Universal Serial Bus (USB) connection.
Ethernet connection.
Identifies high-voltage components.
Ground.
