3: Instrument description 2470 High Voltage SourceMeter Instrument
3-36 2470-901-01 Rev. A / May 2019
Scripts Save Setup menu
The Create Setup menu allows you to save the present settings and configuration lists
of the instrument into a configuration script. You can use this script to recall the
settings.
For more information about user configuration scripts and setups, see Saving setups
(on page 3-45).
Scripts Record menu
The options in the Record menu allow you to record your actions and store them in a
macro script. The script can be run and managed like any other script using the options in
the Scripts menu or remote commands. Note that only settings are stored; no key presses
or front-panel only options are stored (including pressing the OUTPUT ON/OFF switch).
Setting Description
Cancel Macro
Stop recording without saving.
Start Macro
Begin recording your selections.
Stop Macro
Stop recording. You are prompted to enter a Macro Script Name.
System menu
The menus under System in the main menu allow you to configure general instrument settings from
the 2470 front panel. Among these settings are the event log, communications, backlight, time, and
password settings.
