Tektronix Keithley SourceMeter 2470 Reference Manual

2470
High Voltage SourceMeter Instrument Reference Manual Section 14:
TSP command reference
2470-901-01 Rev. A / May 2019 14-267
Example
tsplink.line[3].mode = tsplink.MODE_TRIGGER_OPEN_DRAIN
trigger.tsplinkout[3].release()
Releases trigger line 3.
Also see
trigger.tsplinkout[N].assert() (on page 14-264)
tsplink.line[N].mode (on page 14-271)
trigger.tsplinkout[N].stimulus
This attribute specifies the event that causes the synchronization line to assert a trigger.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes Restore configuration
Instrument reset
Power cycle
TSP-Link line N reset
Configuration script trigger.EVENT_NONE
Usage
event = trigger.tsplinkout[N].stimulus
trigger.tsplinkout[N].stimulus = event
event
The event identifier for the triggering event (see Details)
N
The trigger line (1 to 3)
Details
To disable automatic trigger assertion on the synchronization line, set this attribute to
trigger.EVENT_NONE.
Do not use this attribute when triggering under script control. Use
trigger.tsplinkout[N].assert() instead.
The event parameters that you can use are described in the table below.
Trigger events
Event description Event constant
Trigger event blender
N
(1 to 2), which combines trigger
events
trigger.EVENT_BLENDERN
A command interface trigger:
 Any remote interface: *TRG
 GPIB only: GET bus command
 USB only: A USBTMC TRIGGER message
 VXI-11: VXI-11 command
device_trigger
trigger.EVENT_COMMAND
Digital input line edge (either rising, falling, or either based on
the configuration of the line) detected on digital input line N
(1 to 6)
trigger.EVENT_DIGION
Front-panel TRIGGER key press
trigger.EVENT_DISPLAY
Appropriate LXI trigger packet is received on LAN trigger
object
N
(1 to 8)
trigger.EVENT_LANN
No trigger event
trigger.EVENT_NONE
