12: SCPI command reference 2470 High Voltage SourceMeter Instrument
12-140 2470-901-01 Rev. A / May 2019
:TRACe:WRITe:READing
This command allows you to write readings into the reading buffer.
Type Affected by Where saved Default value
Usage
For buffers that are set to the writable buffer style:
:TRACe:WRITe:READing "<bufferName>", <readingValue>
:TRACe:WRITe:READing "<bufferName>", <readingValue>, <seconds>
:TRACe:WRITe:READing "<bufferName>", <readingValue>, <seconds>, <fractionalSeconds>
:TRACe:WRITe:READing "<bufferName>", <readingValue>, <seconds>, <fractionalSeconds>,
<status>
For buffers that are set to the full writable buffer style:
:TRACe:WRITe:READing "<bufferName>", <readingValue>, <extraValue>
:TRACe:WRITe:READing "<bufferName>", <readingValue>, <extraValue>, <seconds>
:TRACe:WRITe:READing "<bufferName>", <readingValue>, <extraValue>, <seconds>,
<fractionalSeconds>
:TRACe:WRITe:READing "<bufferName>", <readingValue>, <extraValue>, <seconds>,
<fractionalSeconds>, <status>
A user-supplied string that indicates the name of the buffer
The first value that is recorded in the buffer index
A second value that is recorded in the buffer index (only valid for buffer
style
)
An integer that represents the seconds
The portion of time that represents the fractional seconds
Information about the reading; see Details
Details
This command writes the data you specify into a reading buffer. The reading buffer must be set to the
writable or full writable style, which is set when you make the buffer.
Data must be added in chronological order. If the time is not specified for a reading, it is set to one
integer second after the last reading. As you write the data, the front-panel home screen updates and
displays the reading you entered.
