High Voltage SourceMeter Instrument Reference Manual Section 12:
2470-901-01 Rev. A / May 2019 12-159
:TRIGger:BLOCk:CONFig:PREVious
This command defines a trigger model block that recalls the settings stored at the previous index in a source or
measure configuration list.
Type Affected by Where saved Default value
Instrument reset
Usage
:TRIGger:BLOCk:CONFig:PREVious <blockNumber>, "<configurationList>"
:TRIGger:BLOCk:CONFig:NEXT <blockNumber>, "<configurationList>",
"<configurationList2>"
The sequence of the block in the trigger model
A string that defines the source or measure configuration list to
recall
The second source or measure configuration list from which to
recall settings; the type must be opposite of
Details
The Config List Prev block defines a trigger model block that recalls the settings stored at the
previous index in a source or measure configuration list if a single configuration list is specified. If
both measure and source configuration lists are specified, measure and source settings are each
recalled from the previous index in each list when this block is reached. The index numbers recalled
may not match; it depends on the number of indexes in each list and what index number each list is
on.
The configuration list previous index trigger block type recalls the previous index in a configuration
list. It configures the source or measure settings of the instrument based on the settings at that index.
The trigger model executes the settings at that index before the next block is executed.
The first time the trigger model encounters this block, the last index in the configuration list is recalled
if the list has not already had an index recalled by the recall block command in an earlier trigger
model block. If the configuration list has recalled an index with the recall block, the previous index in
the list is called instead of the last. For example, the recall block recalls index 1 by default, so if the
trigger model uses a recall block before this one, the first time the previous block is reached after that
recall, the last index is recalled. However, if the recall block recalled index 3, the previous block would
recall index 2. Each subsequent time trigger model execution reaches a configuration list previous
block for this configuration list, it goes backward one index. When the first index in the list is reached,
it goes to the last index in the configuration list.
The configuration lists must be defined before you can use this block.
Example
TRIG:BLOC:CONF:PREV 14, "SETTINGS_LIST"
Set trigger block 14 to restore the settings
from the previous index that is stored in the
configuration list
.
Also see
Configuration lists (on page 4-83)
