2470
High Voltage SourceMeter Instrument Reference Manual Section 12:
SCPI command reference
2470-901-01 Rev. A / May 2019 12-47
[:SENSe[1]]:<function>:DELay:USER<n>
This command sets a user-defined delay that you can use in the trigger model.
Type Affected by Where saved Default value
Command and query Recall settings
Instrument reset
Power cycle
Measure configuration list
Function change
Save settings
Measure configuration list
0
Usage
[:SENSe[1]]:<function>:DELay:USER<n> <delayTime>
[:SENSe[1]]:<function>:DELay:USER<n> <DEF|MIN|MAX>
[:SENSe[1]]:<function>:DELay:USER<n>?
[:SENSe[1]]:<function>:DELay:USER<n>? <DEF|MIN|MAX>
<function>
The measure function:
 Current: CURRent[:DC]
 Resistance: RESistance
 Voltage:
VOLTage[:DC]
<n>
The user delay to which this time applies (1 to 5)
<delayTime>
The delay (0 for no delay, or 167 ns to 10 ks)
<DEF|MIN|MAX>
The DEFault, MINimum, or MAXimum value
Details
To use this command in a trigger model, assign the delay to the dynamic delay block using the
corresponding MEAS<n> parameter that matches the delay number specified here (see the Exampl
e
below).
The delay is specific to the selected function.
Example
:CURRent:DELay:USER1 0.2
:TRIGger:BLOCk:DELay:DYNamic 6, MEAS1
Set user delay 1 to 0.2 s for current
measurements. Set trigger block 6 to be a
dynamic delay that is set to user delay 1 for
the function being measured.
Also see
:TRIGger:BLOCk:DELay:DYNamic (on page 12-162)
