B: Status model 2470 High Voltage SourceMeter Instrument
B-22 2470-901-01 Rev. A / May 2019
SRQ on error
This example shows you how to generate a service request (SRQ) when an instrument error event
occurs.
Using SCPI commands:
*RST
SYST:CLE
STAT:CLE
*SRE 4
MAKEERROR
Using TSP commands:
reset()
-- Clear Error Queue so EAV bit can go low.
eventlog.clear()
-- Clear the status byte.
status.clear()
-- Enable SRQ on error available.
status.request_enable = status.EAV
-- Send a line of code that will generate an error event.
beeper = 1
SRQ when reading buffer becomes full
This example shows you how to generate a service request (SRQ) when the 2470 reading buffer is
full. You can use this to notify the controlling computer that it needs to read back the data and empty
the buffer. After configuring the status model, this code configures the default reading buffer 1 to a
size of 100, and then configures the 2470 to fill the buffer. After the buffer is full, the instrument
generates an SRQ and returns the data.
Using SCPI commands:
*RST
STAT:CLE
STAT:OPER:MAP 0, 4918, 4917
STAT:OPER:ENAB 1
*SRE 128
TRAC:CLE
TRAC:POIN 100, "defbuffer1"
SOUR:VOLT:RANG 1
SOUR:VOLT 1
SOUR:VOLT:ILIM 10e-3
COUNT 100
OUTP ON
READ? "defbuffer1"
OUTP OFF
TRAC:DATA? 1, 100, "defbuffer1", READ
