Tektronix Keithley SourceMeter 2470

Section
5: Source-measure considerations 2470 High Voltage SourceMeter Instrument
Reference Manual
5-28 2470-901-01 Rev. A / May 2019
For more information on these operations, see the following topics:
• Filtering measurement data (on page 5-25)
• Relative offset (on page 4-46)
• Calculations that you can apply to measurements (on page 4-49)
• Limit testing and binning (on page 4-66)
Reset default values
When you turn instrument power on and off or send a reset command, many of the settings in the
instrument are reset to their default values.
The settings that are affected are listed in the following tables. The tables show SCPI, TSP, and
front-panel settings for each setting. They are sorted alphabetically by the name of the SCPI
command.
Default values
Math and limit reset values
Setting
Default value on
reset
MENU > Measure > Calculations > Filter > Config > Filter
Count
[:SENSe[1]]:<function>:AVERage:COUNt (on page 12-42)
smu.measure.filter.count (on page 14-124)
10
MENU > Measure > Calculations > Filter
[:SENSe[1]]:<function>:AVERage[:STATe] (on page 12-43)
smu.measure.filter.enable (on page 14-125)
Off
MENU > Measure > Calculations > Filter > Config > Filter
Type
[:SENSe[1]]:<function>:AVERage:TCONtrol (on page 12-44)
smu.measure.filter.type (on page 14-126)
Repeat
MENU > Measure > Calculations > Math > Config
:CALCulate[1]:<function>:MATH:FORMat (on page 12-10)
smu.measure.math.format (on page 14-135)
Percent
MENU > Measure > Calculations > Math > Config > Math
Format > mx+b > b (Offset)
:CALCulate[1]:<function>:MATH:MBFactor (on page 12-11)
smu.measure.math.mxb.bfactor (on page 14-136)
0
MENU > Measure > Calculations > Math > Config > Math
Format > mx+b >m (Scalar)
:CALCulate[1]:<function>:MATH:MMFactor (on page 12-13)
smu.measure.math.mxb.mfactor (on page 14-137)
1
MENU > Measure > Calculations > Math > Config > Math
Format > Zero Reference
:CALCulate[1]:<function>:MATH:PERCent (on page 12-14)
smu.measure.math.percent (on page 14-138)
1.0
