High Voltage SourceMeter Instrument Reference Manual Section 12:
2470-901-01 Rev. A / May 2019 12-145
This command does not indicate if an overrun occurred in any other part of the trigger model or in any
other trigger object that is monitoring the event. It also is not an indication of an action overrun.
Example
If an event was ignored, the output is 1.
If an event was not ignored, the output is
.
Also see
:TRIGger:BLENder<n>:CLEar (on page 12-143)
:TRIGger:BLENder<n>:STIMulus<m>
This command specifies the events that trigger the blender.
Type Affected by Where saved Default value
Instrument reset
Power cycle
Usage
:TRIGger:BLENder<n>:STIMulus<m> <event>
:TRIGger:BLENder<n>:STIMulus<m>?
The blender number (up to two)
The stimulus input number (1 to 4)
Details
There are four stimulus inputs that can each select a different event.
Use none to disable the blender input.
The <event> parameter may be any of the trigger events shown in the following table.
Trigger events
Event description Event constant
Trigger event blender <n> (up to two), which combines trigger
events
A command interface trigger:
 Any remote interface: *TRG
 GPIB only: GET bus command
 USB only: A USBTMC TRIGGER message
 VXI-11: VXI-11 command
Line edge (either rising, falling, or either based on the
configuration of the line) detected on digital input line
(1 to 6)
Front-panel TRIGGER key press
Appropriate LXI trigger packet is received on LAN trigger object
<n>
(1 to 8)
