High Voltage SourceMeter Instrument Reference Manual Section 12:
2470-901-01 Rev. A / May 2019 12-181
Trigger events
Event description Event constant
<n>
(up to two), which combines trigger
events
A command interface trigger:
 Any remote interface: *TRG
 GPIB only: GET bus command
 USB only: A USBTMC TRIGGER message
 VXI-11: VXI-11 command
Line edge (either rising, falling, or either based on the
configuration of the line) detected on digital input line
(1 to 6)
Front-panel TRIGGER key press
Appropriate LXI trigger packet is received on LAN trigger object
<n>
(1 to 8)
Notify trigger block <n> (1 to 8); the trigger model generates a
trigger event when it executes the notify block
Source limit condition occurs
Trigger timer <n> (1 to 4) expired
Line edge detected on TSP-Link synchronization line <n> (1 to 3)
Example
Set the timer 1 trigger event as the source for the LAN packet 1
trigger stimulus.
Also see
:TRIGger:LAN<n>:OUT:CONNect:STATe (on page 12-177)
:TRIGger:LOAD "ConfigList"
This command loads a predefined trigger model configuration that uses source and measure configuration lists.
Type Affected by Where saved Default value
Usage
:TRIGger:LOAD "ConfigList", "<measureConfigList>", "<sourceConfigList>"
:TRIGger:LOAD "ConfigList", "<measureConfigList>", "<sourceConfigList>", <delay>
:TRIGger:LOAD "ConfigList", "<measureConfigList>", "<sourceConfigList>", <delay>,
"<bufferName>"
A string that contains the name of the measurement configuration list to
A string that contains the name of the source configuration list to use
The delay time before each measurement (167 ns to 10 ks); default is 0 for
no delay
A string that indicates the reading buffer; the default buffers (defbuffer1
or defbuffer2) or the name of a user-defined buffer; if no buffer is
specified,
is used
