12: SCPI command reference 2470 High Voltage SourceMeter Instrument
12-162 2470-901-01 Rev. A / May 2019
:TRIGger:BLOCk:DELay:DYNamic
This command adds a user delay to the execution of the trigger model.
Type Affected by Where saved Default value
Command only Recall settings
Instrument reset
Save settings Not applicable
Usage
:TRIGger:BLOCk:DELay:DYNamic <blockNumber>, <userDelay>
The sequence of the block in the trigger model
The number of the user delay:
 SOURce<n>, where <n> is the number of the user delay (1 to 5) set by
:SOURce[1]:<function>:DELay:USER<n>
 MEASure<n>, where <n> is the number of the user delay (1 to 5) set by
[:SENSe[1]]:<function>:DELay:USER<n>
Details
When trigger model execution reaches a dynamic delay block, it stops normal measurement and
trigger model operation for the time set by the delay. Background measurements continue to be
made.
Each measure function can have up to five unique user delay times (M1 to M5). Each source function
can also have up to five unique user delay times (S1 to S5). The delay time is set by the user-delay
command, which is only available over a remote interface.
Example
:TRIG:BLOC:SOUR:STAT 1, ON
:TRIG:BLOC:DEL:DYN 2, SOUR1
:TRIG:BLOC:MEAS 3
:TRIG:BLOC:SOUR:STAT 4, OFF
:TRIG:BLOC:BRAN:COUN 5, 10, 1
:INIT
Set user delay 1 for the voltage source to 5 s.
Set trigger block 1 to turn the source output on.
Set trigger block 2 to a dynamic delay that calls source user
delay 1.
Set trigger block 3 to make a measurement.
Set trigger block 4 to turn the source output off.
Set trigger block 5 to branch to block 1 ten times.
Also see
[:SENSe[1]]:<function>:DELay:USER<n> (on page 12-47)
:SOURce[1]:<function>:DELay:USER<n> (on page 12-75)
