Section
12: SCPI command reference 2470 High Voltage SourceMeter Instrument
Reference Manual
12-10 2470-901-01 Rev. A / May 2019
Example
*SAV 2
Saves the instrument settings in memory location 2.
Also see
Saving setups (on page 3-45)
*RCL (on page 12-9)
CALCulate subsystem
The commands in this subsystem configure and control the math and limit operations.
:CALCulate[1]:<function>:MATH:FORMat
This command specifies which math operation is performed on measurements when math operations are
enabled.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
PERC
Usage
:CALCulate[1]:<function>:MATH:FORMat <operation>
:CALCulate[1]:<function>:MATH:FORMat?
<function>
The measure function:
 Current: CURRent[:DC]
 Resistance: RESistance
 Voltage:
VOLTage[:DC]
<operation>
The name of the math operation:
 y = mx+b: MXB
 Percent: PERCent
 Reciprocal: RECiprocal
Details
This specifies which math operation is performed on measurements for the selected measurement
function.
You can choose one of the following math operations:
• y = mx+b: Manipulate normal display readings by adjusting the m and b factors.
• Percent: Displays measurements as the percentage of deviation from a specified reference
c
onstant.
• Reciprocal: The reciprocal math operation displays measurement values as reciprocals. The
di
splayed value is 1/X, where X is the measurement value (if relative offset is being used, this is
the measured value with relative offset applied).
