12: SCPI command reference 2470 High Voltage SourceMeter Instrument
Reference Manual
12-138 2470-901-01 Rev. A / May 2019
Example
TRACe:MAKE "MyBuffer", 100
COUN 5
TRACe:TRIG "MyBuffer"
TRACe:DATA? 1,5, "MyBuffer", rel
Create a buffer called MyBuffer with a maximum size of 100.
Make readings and store them in MyBuffer.
Recall the relative time when the data points were measured
for the first five readings in the buffer.
Example output:
0.000000,0.408402,0.816757,1.208823,1.617529
Also see
[:SENSe[1]]:COUNt (on page 12-66)
[:SENSe[1]]:FUNCtion[:ON] (on page 12-67)
:TRACe:DATA? (on page 12-120)
:TRACe:MAKE (on page 12-127)
:TRACe:WRITe:FORMat
This command sets the units and number of digits of the readings that are written into the reading buffer.
Type Affected by Where saved Default value
Command only Recall settings
Instrument reset
Power cycle
Save settings Not applicable
Usage
:TRACe:WRITe:FORMat "<bufferName>", <units>, <displayDigits>
:TRACe:WRITe:FORMat "<bufferName>", <units>, <displayDigits>, <extraUnits>
:TRACe:WRITe:FORMat "<bufferName>", <units>, <displayDigits>, <extraUnits>,
<extraDigits>
<bufferName>
A user-supplied string that indicates the name of the buffer
<units>
The units for the first measurement in the buffer index:
 AMP
 AMP_AC
 CELSius
 DECibel
 FAHRenheit
 FARad
 HERTz
 KELVin

NONE
 OHM
 PERCent
 RATio
 RECiprocal
 SECond
 VOLT
 VOLT_AC
 WATT

X
<displayDigits>
The number of digits to use for the first measurement: 3 to 8
<extraUnits>
The units for the second measurement in the buffer index; the selections are the
same as <units> (only valid for buffer style FULLWRITable); if this parameter is
not specified, the value for
<units>
is used
<extraDigits>
The number of digits to use for the second measurement; the selections are the
same as <displayDigits> (only valid for buffer style FULLWRITable); if this
parameter is not specified, the value for <displayDigits> is used

Tektronix Keithley SourceMeter 2470 Specifications

General

Model	2470
Type	SourceMeter
Category	Measuring Instruments
Channels	1
Voltage Source Range	±1000 V
Current Source Range	±1 A
Power	100 W
Current Measurement Resolution	10 pA
Measurement Resolution	6½ digits
Display	5 inch capacitive touchscreen
Interface	USB, GPIB, Ethernet
Supported Communication Protocols	SCPI
Input/Output Connectors	4-wire
