Tektronix Keithley SourceMeter 2470 Reference Manual

Section
12: SCPI command reference 2470 High Voltage SourceMeter Instrument
Reference Manual
12-176 2470-901-01 Rev. A / May 2019
Details
The trigger event detector enters the detected state when an event is detected. This function clears a
trigger event detector and discards the history of the trigger packet.
This function clears all overruns associated with this LAN trigger.
Example
:TRIG:LAN5:IN:CLE
Clears the event detector with LAN packet 5.
Also see
:TRIGger:LAN<n>:IN:OVERrun? (on page 12-177)
:TRIGger:LAN<n>:IN:EDGE
This command sets the trigger operation and detection mode of the specified LAN event.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Save settings
EITH
Usage
:TRIGger:LAN<n>:IN:EDGE <mode>
:TRIGger:LAN<n>:IN:EDGE?
<n>
The LAN event number (1 to 8)
<mode>
The trigger mode; see the Details for more information
Details
This command controls how the trigger event detector and the output trigger generator operate on the
given trigger. These settings are intended to provide behavior similar to the digital I/O triggers.
LAN trigger mode values
Mode Trigger packets detected as input
LAN trigger packet generated for
output with a…
EITHer
Rising or falling edge (positive or negative state)
negative state
FALLing
Falling edge (negative state)
negative state
RISing
Rising edge (positive state)
positive state
Example
:TRIG:LAN2:IN:EDGE FALL
Set the LAN trigger mode for event 2 to falling edge.
Also see
Digital I/O (on page 8-12)
TSP-Link System Expansion Interface (on page 9-1)
