Tektronix Keithley SourceMeter 2470 Reference Manual

Section
14: TSP command reference 2470 High Voltage SourceMeter Instrument
Reference Manual
14-178 2470-901-01 Rev. A / May 2019
smu.source.xlimit.tripped
This attribute indicates if the source exceeded the limits that were set for the selected measurements.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (R)
Yes
Function change
Not saved
Not applicable
Usage
state = smu.source.xlimit.tripped
state
Indicates if the limit has been tripped:
 Not tripped = 0
 Tripped =
1
x
The function whose limit was tripped:
 v: voltage

i
: current
Details
You can use this command to check the limit state of the source.
If the limits were exceeded, the instrument clamps the source to keep the source within the set limits.
If you check the limit for the source that is not presently selected, nil is returned.
Example
print(smu.source.vlimit.tripped)
Check the state of the source limit for voltage. If
the limit was exceeded, the output is:
smu.ON
Also see
smu.source.xlimit.level (on page 14-177)
smu.terminals
This attribute describes which set of input and output terminals the instrument is using.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Restore configuration
Instrument reset
Power cycle
Measure configuration list
Configuration script
Measure configuration list
smu.TERMINALS_FRONT
Usage
terminals = smu.terminals
smu.terminals = terminals
terminals
Use the front-panel input and output terminals: smu.TERMINALS_FRONT
Use the rear-panel input and output terminals:
smu.TERMINALS_REAR
