12: SCPI command reference 2470 High Voltage SourceMeter Instrument Referen
ce Manual
12-152 2470-901-01 Rev. A / May 2019
Example
:TRIG:BLOC:BRAN:EVEN 6, DISP, 2
When the trigger model reaches this block, if the front-panel TRIGGER key has been pressed, the trigger
model returns to block 2. If the TRIGGER key has not been pressed, the trigger model continues to block 7 (the
next block in the trigger model).
Also see
On event block (on page 8-37)
:TRIGger:BLOCk:BRANch:LIMit:CONStant
This command defines a trigger model block that goes to a specified block if a measurement meets preset criteria.
Type Affected by Where saved Default value
Command only
Recall settings
Instrument reset
Power cycle
Save settings
Not applicable
Usage
:TRIGger:BLOCk:BRANch:LIMit:CONStant <blockNumber>, <limitType>, <limitA>, <limitB>,
<branchToBlock>
:TRIGger:BLOCk:BRANch:LIMit:CONStant <blockNumber>, <limitType>, <limitA>, <limitB>,
<branchToBlock>, <measureBlock>
<blockNumber>
The sequence of the block in the trigger model
<limitType>
The type of limit (ABOVe, BELow, INside, or OUTside)
<limitA>
The limit that the measurement is tested against; if
limitType
is set to:
 ABOVe: This value is ignored
 BELow: The measurement must be below this value
 INside: The low limit that the measurement is compared against
 OUTside: The low limit that the measurement is compared against
<limitB>
The upper limit that the measurement is tested against; if limitType is set to:
 ABOVe: The measurement must be above this value
 BELow: This value is ignored
 INside: The high limit that the measurement is compared against
 OUTside
: The high limit that the measurement is compared against
<branchToBlock>
The block number of the trigger model block to execute when the measurement
meets the defined criteria
<measureBlock>
The block number of the measure block that makes the measurements to be
compared; if this is 0 or undefined, the trigger model uses the previous measure
block
