Section

12: SCPI command reference 2470 High Voltage SourceMeter Instrument

Reference Manual

12-124 2470-901-01 Rev. A / May 2019

:TRACe:DELete

This command deletes a user-defined reading buffer.

Type Affected by Where saved Default value

Command only

Not applicable

Usage

:TRACe:DELete "<bufferName>"

A string that contains the name of the user-defined reading buffer to delete

Details

You cannot delete the default reading buffers, defbuffer1 and defbuffer2.

Example

TRAC:DEL "testData"

Delete the testData buffer.

Also see

Reading buffers (on page 6-1)

Remote buffer operation (on page 6-25)

:TRACe:MAKE (on page 12-127)
