High Voltage SourceMeter Instrument Reference Manual Section 12:
2470-901-01 Rev. A / May 2019 12-157
:TRIGger:BLOCk:BUFFer:CLEar
This command defines a trigger model block that clears the reading buffer.
Type Affected by Where saved Default value
Command only Recall settings
Instrument reset
Save settings Not applicable
Usage
:TRIGger:BLOCk:BUFFer:CLEar <blockNumber>
:TRIGger:BLOCk:BUFFer:CLEar <blockNumber>, "<bufferName>"
The sequence of the block in the trigger model
The name of the buffer, which must be an existing buffer; if no buffer is defined,
defbuffer1
is used
Details
When trigger model execution reaches the buffer clear trigger block, the instrument empties the
specified reading buffer. The specified buffer can be the default buffer or a buffer that you defined.
Example
TRIG:BLOC:BUFF:CLE 1
TRIG:BLOC:MEAS 2
TRIG:BLOC:BRAN:COUN 3, 5, 2
TRIG:BLOC:DEL:CONS 4, 1
TRIG:BLOC:BRAN:COUN 5, 3, 2
Reset trigger model settings.
Clear defbuffer1 at the beginning of the trigger model.
Loop and make 5 readings.
Delay 1 s.
Loop three more times back to block 2.
At end of execution, 15 readings are stored in defbuffer1.
Also see
Buffer clear block (on page 8-28)
:TRACe:MAKE (on page 12-127)
