Tektronix Keithley SourceMeter 2470 Reference Manual

Section
14: TSP command reference 2470 High Voltage SourceMeter Instrument
Reference Manual
14-212 2470-901-01 Rev. A / May 2019
trigger.lanout[N].logic
This attribute sets the logic on which the trigger event detector and the output trigger generator operate on the
given trigger line.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Restore configuration
Instrument reset
Power cycle
Configuration script
trigger.LOGIC_NEGATIVE
Usage
logicType = trigger.lanout[N].logic
trigger.lanout[N].logic = logicType
logicType
The type of logic:
 Positive: trigger.LOGIC_POSITIVE
 Negative:
trigger.LOGIC_NEGATIVE
N
The LAN event number (1 to 8)
Example
trigger.lanout[2].logic = trigger.LOGIC_POSITIVE
Set the logic for LAN trigger line 2 to positive.
Also see
None
trigger.lanout[N].protocol
This attribute sets the LAN protocol to use for sending trigger messages.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Restore configuration
Instrument reset
Power cycle
Configuration script
lan.PROTOCOL_TCP
Usage
protocol = trigger.lanout[N].protocol
trigger.lanout[N].protocol = protocol
protocol
The protocol to use for messages from the trigger:
 lan.PROTOCOL_TCP
 lan.PROTOCOL_UDP

lan.PROTOCOL_MULTICAST
N
The LAN event number (1 to 8)
