12: SCPI command reference 2470 High Voltage SourceMeter Instrument
12-20 2470-901-01 Rev. A / May 2019
The results of the limit test for limit Y:
• NONE: Test passed; the measurement is between the upper and lower limits
• HIGH: Test failed; the measurement exceeded the upper limit
• LOW: Test failed; the measurement exceeded the lower limit
• BOTH: Test failed; the measurement exceeded both limits
Example
:CALC2:VOLT:LIM1:CLE:AUTO OFF
:CALC2:VOLT:LIM1:AUD FAIL
:CALC2:VOLT:LIM1:LOW 0.25
:CALC2:VOLT:LIM1:UPP 2.5
:CALC2:VOLT:LIMIT1:STAT ON
:READ?
:CALC2:VOLT:LIMIT1:FAIL?
:CALC2:VOLT:LIM1:CLE
Enable the beeper for limit 1 when a voltage measurement
exceeds the limit.
Set lower limit 1 for voltage to 0.25 V.
Set upper limit 1 for voltage to 2.5 V.
Enable limit 1 testing for voltage.
Make a reading; the limit is checked and results display on the
front panel.
Return the test results; example output if the test fails on the
low limit:
LOW
Also see
:CALCulate2:<function>:LIMit<Y>:CLEar:AUTO (on page 12-17)
:CALCulate2:<function>:LIMit<Y>:CLEar[:IMMediate] (on page 12-18)
:CALCulate2:<function>:LIMit<Y>:STATe (on page 12-22)
Limit testing and binning (on page 4-66)
:CALCulate2:<function>:LIMit<Y>:LOWer[:DATA]
This command specifies the lower limit for limit tests.
Type Affected by Where saved Default value
Command and query Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
-1
Usage
:CALCulate2:<function>:LIMit<Y>:LOWer[:DATA] <n>
:CALCulate2:<function>:LIMit<Y>:LOWer[:DATA] <DEF|MIN|MAX>
:CALCulate2:<function>:LIMit<Y>:LOWer[:DATA]?
 Current: CURRent[:DC]
 Resistance: RESistance
 Voltage: VOLTage[:DC]
The low limit value of limit
Y
(-9.99999E+11 to 9.99999E+11)
The DEFault, MINimum, or MAXimum value
