High Voltage SourceMeter Instrument Reference Manual Section 12:
SCPI command reference
2470-901-01 Rev. A / May 2019 12-23
Also see
:CALCulate2:<function>:LIMit<Y>:CLEar:AUTO (on page 12-17)
:CALCulate2:<function>:LIMit<Y>:CLEar[:IMMediate] (on page 12-18)
:CALCulate2:<function>:LIMit<Y>:FAIL? (on page 12-19)
:CALCulate2:<function>:LIMit<Y>:LOWer[:DATA] (on page 12-20)
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA] (on page 12-23)
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA]
This command specifies the upper limit for a limit test.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
1
Usage
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA] <value>
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA] <DEF|MIN|MAX>
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA]?
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA]? <DEF|MIN|MAX>
<function>
The measure function:
 Current: CURRent[:DC]
 Resistance: RESistance
 Voltage: VOLTage[:DC]
<Y>
Limit number: 1 or 2
<value>
The value of the upper limit (
−
9.99999e+11 to +9.99999e+11) or DEFault,
MINimum, or MAXimum
<DEF|MIN|MAX>
The DEFault, MINimum, or MAXimum value
Details
This command sets the high limit for the limit Y test for the selected measurement function. When limit
Y testing is enabled, the instrument generates a fail indication when the measurement value is more
than this value.
If you send this command without the <function> parameter, it will set the limit for all measure
f
unctions.
