12: SCPI command reference 2470 High Voltage SourceMeter Instrument
Reference Manual
12-192 2470-901-01 Rev. A / May 2019
:TRIGger:TIMer<n>:CLEar
This command clears the timer event detector and overrun indicator for the specified trigger timer number.
Type Affected by Where saved Default value
Command only
Not applicable
Not applicable
Not applicable
Usage
:TRIGger:TIMer<n>:CLEar
<n>
Trigger timer number (1 to 4)
Details
This command sets the timer event detector to the undetected state and resets the overrun indicator.
Example
:TRIG:TIM1:CLE
Clears trigger timer 1.
Also see
:TRIGger:TIMer<n>:COUNt (on page 12-192)
:TRIGger:TIMer<n>:STARt:OVERrun? (on page 12-195)
:TRIGger:TIMer<n>:COUNt
This command sets the number of events to generate each time the timer generates a trigger event or is enabled
as a timer or alarm.
Type Affected by Where saved Default value
Command and query Recall settings
Instrument reset
Power cycle
Save settings 1
Usage
:TRIGger:TIMer<n>:COUNt <count>
:TRIGger:TIMer<n>:COUNt?
<n>
Trigger timer number (1 to 4)
<count>
The number of times to repeat the trigger (0 to 1,048,575)
Details
If the count is set to a number greater than 1, the timer automatically starts the next trigger timer
delay at the expiration of the previous delay.
Set the count to zero (0) to cause the timer to generate trigger events indefinitely.
If you use the trigger timer with a trigger model, make sure the count value is the same or more than
any count values expected in the trigger model.
Example 1
TRIG:TIM2:COUN 4
Set the number of events to generate for trigger timer 2 to four.
