12: SCPI command reference 2470 High Voltage SourceMeter Instrument
12-198 2470-901-01 Rev. A / May 2019
Example
DIG:LINE1:MODE TRIG,IN
DIG:LINE2:MODE TRIG,OUT
TRIG:TIM1:DEL 35e-3
TRIG:TIM1:STAR:STIM DIG1
TRIG:DIG2:OUT:STIM TIM1
Reset the instrument to default settings. Set digital I/O line 1 for
use as a trigger input.
Set digital I/O line 2 for use as a trigger output.
Set timer 1 to delay 35 ms.
Set timer 1 to start delaying once the digital I/O 1 event is
detected.
Set digital I/O line 2 to output a pulse once the timer 1 event is
Also see
None
:TRIGger:TIMer<n>:STATe
This command enables the trigger timer.
Type Affected by Where saved Default value
Instrument reset
Power cycle
Usage
:TRIGger:TIMer<n>:STATe <state>
:TRIGger:TIMer<n>:STATe?
Trigger timer number (1 to 4)
Disable the trigger timer: OFF or 0
Enable the trigger timer: ON or 1
Details
When this command is set to on, the timer performs the delay operation.
When this command is set to off, there is no timer on the delay operation.
You must enable a timer before it can use the delay settings or the alarm configuration. For expected
results from the timer, it is best to disable the timer before changing a timer setting, such as delay or
start seconds.
To use the timer as a simple delay or pulse generator with digital I/O lines, make sure the timer start
time in seconds and fractional seconds is configured for a time in the past. To use the timer as an
alarm, configure the timer start time in seconds and fractional seconds for the desired alarm time.
Example 1
TRIG:DIG3:OUT:STIM TIM2
SYSTem:TIME?
TRIG:TIM2:START:SECONDS <current time> + 60
TRIG:TIM2:STAT ON
To configure timer 2 for an alarm to fire 1
minute from now and output a pulse on
digital I/O line 3, query to get the current
time. Add 60 s to that value and use that to
configure the start seconds. Enable the
