Tektronix Keithley SourceMeter 2470 Reference Manual

Section
14: TSP command reference 2470 High Voltage SourceMeter Instrument
Reference Manual
14-172 2470-901-01 Rev. A / May 2019
Example
reset()
smu.source.func = smu.FUNC_DC_CURRENT
smu.source.range = 1
smu.measure.func = smu.FUNC_DC_VOLTAGE
smu.measure.range = 20
smu.source.sweeplinearstep("CurrLogSweep", -1.05, 1.05, .25, 10e-3, 1,
smu.RANGE_FIXED)
trigger.model.initiate()
Reset the instrument to its defaults.
Set the source function to current.
Set the source range to 1 A. Set the measure function to voltage with a range of 20 V.
Set up a linear step sweep that sweeps from -1.05 A to 1.05 A in 0.25 A increments with a source delay of
1 ms, a sweep count of 1, and a fixed source range. Name the configuration list that is created for this sweep
CurrLogSweep.
Start the sweep.
Also see
Sweep operation (on page 4-54)
smu.source.sweeplist()
This function sets up a sweep based on a configuration list, which allows you to customize the sweep.
Type TSP-Link accessible
Affected by Where saved Default value
Function
Yes
Usage
smu.source.sweeplist("configListName")
smu.source.sweeplist("configListName", index)
smu.source.sweeplist("configListName", index, sDelay)
smu.source.sweeplist("configListName", index, sDelay, count)
smu.source.sweeplist("configListName", index, sDelay, count, failAbort)
smu.source.sweeplist("configListName", index, sDelay, count, failAbort, bufferName)
configListName
The name of the source configuration list that the sweep uses; this must be defined
before sending this command
index
The index in the configuration list where the sweep starts; default is 1
sDelay
The delay between measurement points; default is 0 for no delay or you can set a
specific delay value from 50 µs to 10 ks
count
The number of times to run the sweep; default is 1:
 Infinite loop: smu.INFINITE
 Finite loop:
1
to
268,435,455
failAbort
Complete the sweep if the source limit is exceeded: smu.OFF
Abort the sweep if the source limit is exceeded:
smu.ON
(default)
bufferName
The name of a reading buffer; the default buffers (defbuffer1 or defbuffer2) or
the name of a user-defined buffer; if no buffer is specified, this parameter defaults to
defbuffer1
