12: SCPI command reference 2470 High Voltage SourceMeter Instrument
12-180 2470-901-01 Rev. A / May 2019
Details
The LAN trigger listens for trigger messages on all the supported protocols. However, it uses the
designated protocol for sending outgoing messages.
After you change this setting, you must re-connect the LAN trigger event generator before you can
send outgoing event messages.
When multicast is selected, the trigger IP address is ignored and event messages are sent to the
multicast address 224.0.23.159.
Example
:TRIG:LAN1:OUT:PROT TCP
:TRIG:LAN1:OUT:CONN:STAT
Set the LAN protocol for trigger messages to be TCP and
re-connect the LAN trigger event generator.
Also see
:TRIGger:LAN<n>:OUT:CONNect:STATe (on page 12-177)
:TRIGger:LAN<n>:OUT:IP:ADDRess (on page 12-178)
:TRIGger:LAN<n>:OUT:STIMulus
This command specifies events that cause this trigger to assert.
Type Affected by Where saved Default value
Command and query Recall settings
Instrument reset
Save settings NONE
Usage
:TRIGger:LAN<n>:OUT:STIMulus <LANevent>
:TRIGger:LAN<n>:OUT:STIMulus?
A number specifying the trigger packet over the LAN for which to set or query the
trigger source (1 to 8)
The LAN event that causes this trigger to assert
Details
This attribute specifies which event causes a LAN trigger packet to be sent for this trigger. Set the
event to one of the existing trigger events, which are shown in the following table.
Setting this attribute to none disables automatic trigger generation.
If any events are detected before the trigger LAN connection is sent, the event is ignored and the
action overrun is set.
