High Voltage SourceMeter Instrument Reference Manual Section 12: SCPI command refere
2470-901-01 Rev. A / May 2019 12-11
Math calculations are applied to the input signal after relative offset and before limit tests.
If you send this command without the <function> parameter, it will set the state of the math format
for all measure functions.
Example
:CALC:VOLT:MATH:MMF 0.80
:CALC:VOLT:MATH:MBF 50
Set the math function for voltage measurements to mx+b.
Set the scale factor for voltage measurements to 0.80.
Set the offset factor to 50.
Enable the math function.
Also see
Calculations that you can apply to measurements (on page 4-49)
:CALCulate[1]:<function>:MATH:MBFactor (on page 12-11)
:CALCulate[1]:<function>:MATH:MMFactor (on page 12-13)
:CALCulate[1]:<function>:MATH:PERCent (on page 12-14)
:CALCulate[1]:<function>:MATH:STATe (on page 12-15)
:CALCulate[1]:<function>:MATH:MBFactor
This command specifies the offset, b, for the y = mx + b operation.
Type Affected by Where saved Default value
Command and query Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
0
Usage
:CALCulate[1]:<function>:MATH:MBFactor <n>
:CALCulate[1]:<function>:MATH:MBFactor <DEF|MIN|MAX>
:CALCulate[1]:<function>:MATH:MBFactor?
:CALCulate[1]:<function>:MATH:MBFactor? <DEF|MIN|MAX>
The measure function:
 Current: CURRent[:DC]
 Resistance: RESistance
 Voltage:
The offset for the y = mx + b operation; the valid range is −1e12 to +1e12
The DEFault, MINimum, or MAXimum value
